RSD115W   Switch single position single pole 15A 120/277V white decorator Hubbell
+8
+7
+6
+5
+4
+3
+2

RSD115W Switch single position single pole 15A 120/277V white decorator Hubbell

SKU RSD115W
$8.71
In stock: 2 available
1
Save this product for later
Customer reviews
Reviews only from verified customers
No reviews yet. You can buy this product and be the first to leave a review.
Share this product with your friends
ShareSharePin it
RSD115W Switch single position single pole 15A 120/277V white decorator Hubbell
Product Details
UPC: 8.83778E+11
Brand: Hubbell
Weight: 0.15 lbs

Specifications RSD115W CatalogCatalog

Description

Product Details

General

Performance
  • Electrical - Dielectric voltage - Withstands 1,500V AC minimum for 1 minute
  • Electrical - Endurance - 30,000 cycles minimum
  • Electrical - Max. working voltage - 120V
  • Electrical - Overload - 1.5 times rating
  • Environmental - Flammability - UL V0
  • Environmental - Operating temperatures - Maximum continuous 60¬∞C
  • minimum -20¬∞C (without impact)
  • Mechanical - Terminal accommodation - Back and side wire: #14 AWG min. - #12 AWG max. solid and stranded copper wire only
  • push wire: #14 AWG solid copper wire only
UPC 883778101137

Certifications and Compliance

Industry Standard(s)
  • CSA Certified
  • Listed to UL Standard 20

Logistics

Carton Quantity 10
